Brand: IEK

Miniature circuit breaker VA47-100 4P 80A 10kA C IEK

0 | No Reviews
0 Out Of 5 | Reviews & Ratings
  • 5 Star
  • 4 Star
  • 3 Star
  • 2 Star
  • 1 Star

See all customer reviews
Specifications
  • Electronic release: No
  • Rated surge voltage invariability: 6 kV
  • Nominal voltage DC: ≤ 60 B
  • Rated short-circuit breaking capacity Icn EN 60898 at 230 V: 10.0 kA
  • Rated short-circuit breaking capacity Icn EN 60898 at 400 V: 10.0 kA
  • Nominal rated voltage: 400 B
  • Nominal rated current: 80.0 A
  • Primary current: 80 A
  • Number of poles (total): 4
  • Rated short-circuit breaking capacity EN 60898: 10 kA
  • Power loss: 60.0 W
  • Instantaneous release resistance representation: By multiple (Ki)
  • Release resistance representation: By type (A/B/C/D...)
  • Degree of protection (IP): IP20
  • Range of use: Industrial and household
  • Mounting method: DIN-rail (DRA)
  • Mounting rail type: 35x7.5
  • Voltage type: AC/DC
  • Type of electric connection: Screw connection
  • Switch off technique: Thermal, electromagnetic
  • Release characteristic: C
  • Frequency: 50 Hz
  • Width in number of modular spacings: 6
  • Additional equipment possible: Yes
  • Release actuating time in short-circuit tm zone: 0,1 s
  • Current limiting class: 3
  • Ambient class: UHL4
  • Number of protected poles: 4
  • Power poles quantity: 4
  • Max. cross section incoming cable: 35 mm²
  • Built-in depth: 74,3 mm
  • Explosion protection: Without explosion protection
Payments
Bank Transfer Paypal Stripe
Seller Guarantee
  • Shipping Rates Check
  • Cash On Delivery Available
Or Get A Quote For This Product Request For Quote
Noor Kabul Khurasan Limited
Kabul, Afghanistan,
0
Response Time
> 24 Hrs
On-time Delivery Rate
100%
Ask for more details from the seller Contact Seller

Description

Modular circuit breakers (MCB) VA47-100 protect distribution and group circuits with active and inductive loads.

Recommended for use in lead-in distributors of domestic and industrial electric installations.

Specifications

Electronic release: No
Rated surge voltage invariability: 6 kV
Nominal voltage DC: ≤ 60 B
Rated short-circuit breaking capacity Icn EN 60898 at 230 V: 10.0 kA
Rated short-circuit breaking capacity Icn EN 60898 at 400 V: 10.0 kA
Nominal rated voltage: 400 B
Nominal rated current: 80.0 A
Primary current: 80 A
Number of poles (total): 4
Rated short-circuit breaking capacity EN 60898: 10 kA
Power loss: 60.0 W
Instantaneous release resistance representation: By multiple (Ki)
Release resistance representation: By type (A/B/C/D...)
Degree of protection (IP): IP20
Range of use: Industrial and household
Mounting method: DIN-rail (DRA)
Mounting rail type: 35x7.5
Voltage type: AC/DC
Type of electric connection: Screw connection
Switch off technique: Thermal, electromagnetic
Release characteristic: C
Frequency: 50 Hz
Width in number of modular spacings: 6
Additional equipment possible: Yes
Release actuating time in short-circuit tm zone: 0,1 s
Current limiting class: 3
Ambient class: UHL4
Number of protected poles: 4
Power poles quantity: 4
Max. cross section incoming cable: 35 mm²
Built-in depth: 74,3 mm
Explosion protection: Without explosion protection
